STEDI - ST3303 21.5 INCH 32 FLOOD LED DOUBLE ROW ULTRA HIGH OUTPUT LED BAR

STEDI - ST3303 21.5 INCH 32 FLOOD LED DOUBLE ROW ULTRA HIGH OUTPUT LED BAR

$369.99
(No reviews yet) Write a Review

stedi conceptualized a light bar that was diabolic, something excessive, over the top, a real savage. Then, stedi went ahead and made it. No other light bar on the market encapsulates 32 x 10W CREE XM-L2 LEDs inside of 21.5” housing – A world first then?

A SAVAGE CONCEPT

In conceptualising the ST3303 the objective was quite simply to create a light bar that epitomises adjectives like overkill, savage, brutal and excessive. Make no mistake about it, the STEDI ST3303-32L LED bar is for the customer who, like Stedi, live by the modus operandi that too much is just right.

ASTONISHING LEVELS OF PERFORMANCE

Stedi believe that there is no other 21.5 inch light bar on the market at any price point, from any brand that comes even close to offering this level of performance. No other light bar on the market offers 32 x 10W CREE XM-L2 LEDs inside of a 21.5” housing, and still managed to send 16.4A of drive current through to the emitters. The result is a truly astonishing level of light volume, which can only be described as a tsunami of light for as far as the eye could possibly appreciate.

LEGENDARY BUILD QUALITY

Stedi have worked hard to earn their reputation in offering high performance and high quality auxiliary LED lighting systems. They know what works and what doesn’t because they've been there. The ST3303 embodies the best in design and material selection process that are tried and then tested, which is why Stedi guarantee the performance and workmanship for 5 years.

KEY FEATURES

  • 32 x 10W CREE XM-L2 LEDs
  • RFI and EMI supression circuit. Guaranteed to not interfere with Radio and Communication Equipment
  • IP68 - Submersible to 3m
  • High Current Deutsch DTP-2 25A connectors
  • 32mm diameter parabolic reflectors
  • Full Flood Beam
  • Heavy Duty  Adjustable Bottom Mounts.

INCLUDES: Our high current Easy-Fit Plug & Play Wiring Harness. (Switch, Fuse, Relay HB3 and H4 Piggy Back Adaptors)





WHAT’S IN THE BOX

  • ST3303 21.5 Inch LED Light Bar (ALL FLOOD)
  • Easy Fit High Beam Wiring Harness with H4 & HB3 adapters to High Beam
  • 3 x Lower Mountings Brackets with Fasteners
  • Nuts & Bolts (6 x M8 40mm Bolts, 6 x M8 Nuts, 6 x M6 Bolts)

* Standard installation is available for a set additional charge of $150 when selected below.

* Cruisemaster reserve the right to requote installation if requirements are outside of what is considered "Standard"

  Installation is only available from the Cruisemaster Towing Performance Centre (352 Bilsen Road, GEEBUNG 4034). Installs available via booking Mon - Thurs 7.30am - 4.30pm Fri 7.30am - 12.30pm.

SPECIFICATIONS

LUMENS: 33,600Lm

LED: 32 x CREE XM-L2

CURRENT DRAW: 16.4A @ 13.6v

WATERPROOF: IP 68

COLOUR TEMP (CCT): 5700K

FLOOD BEAM ANGLE: 50 Degrees

LENS: OPTICAL GRADE, HARD COATED LEXAN

MATERIAL: A360.0 cast face plate with extruded Aluminium heat-sink

OPERATING TEMP: -40 Deg Celsius, +150 Deg Celsius

LIFE SPAN: 50,000 Hours

WEIGHT: 3.725KG
